Products/DVR Recorders/Hikvision iDS-7204HQHI-M1/XT 4-ch 1080p 1U H.265 AcuSense DVR
Hikvision iDS-7204HQHI-M1/XT 4-ch 1080p 1U H.265 AcuSense DVR−20% OFF

DVR Recorders • SKU: iDS-7204HQHI-M1/XT

Hikvision iDS-7204HQHI-M1/XT 4-ch 1080p 1U H.265 AcuSense DVR

Rs. 31,207Rs. 39,232

The Hikvision iDS-7204HQHI-M1/XT is a 4-channel AcuSense DVR for Turbo HD analogue cameras, recording up to 1080p. AcuSense tells people and vehicles apart from other movement, so you get fewer false alerts from animals, rain or swaying trees. As well as analogue cameras it can take up to 6 IP cameras. It has 1 hard drive bay; the hard drive is sold separately and sized to how many days of footage you want to keep. Watch live and recorded video on your phone with the Hik-Connect app. Enspire supplies it with warranty and can install and set it up anywhere in Sri Lanka.

1

2 Year Warranty

Island-wide Delivery

Key Features

  • 4 channels and 1 HDD 1U AcuSense DVR
  • Support 1-ch Facial Recognition or 2-ch Advanced model Perimeter Protection based on Deep Learning algorithm
  • Support 2-ch AcuSearch Technology
  • Efficient H.265 pro+ compression technology
  • Encoding ability up to 3K/5MP Lite @ 12 fps
  • 5 signals input adaptively (HDTVI/AHD/CVI/CVBS/IP)
  • Up to 6-ch network cameras can be connected
  • Support All channels Motion Detection Technology

Technical Specifications

SATA1 SATA interface, up to 10 TB capacity for each disk
Wi-FiConnectable to Wi-Fi network by Wi-Fi dongle through USB interface
Weight≤ 1.16 kg (2.6 lb)
AHD Input5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
CVBS InputPAL/NTSC
Data SheetDownload PDF
Frame RateMain stream: When 1080p Lite mode not enabled: For 3K stream access: 3K lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps For 5 MP stream access: 5 MP lite@12fps;4 MP…
VGA Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, HDMI/VGA simultaneous output
Audio Input4-ch, RCA (2.0 Vp-p, 1 KΩ), 4-ch via coaxial cable;1-ch (up to 4-ch is optional), RCA (2.0 Vp-p, 1 KΩ),4-ch via coaxial cable
CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
Consumption≤ 18 W
Dual-streamSupport main stream or sub stream
HDCVI Input3K(2880×1620)@20/25 fps, 5MP(2592 × 1944)@20 fps, 4MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
HDMI Output1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, HDMI/VGA simultaneous output
HDTVI Input3K(2960 x 1665)@25/20 fps, 3K(3328x1504)@20fps,2K(2304x1296)@20fps,5 MP(2560 × 1944)@20 fps, 4 MP(2560 × 1440)@25/30 fps,1080P@25/30 fps, 720P@25/30fps
Stream TypeVideo, Video & Audio
Alarm In/OutN/A (optional to support);4/1
Audio Output1-ch, RCA (Linear, 1 KΩ)
ManufacturerHikvision
Power Supply12 VDC, 1.5 A
Audio Bitrate64 Kbps
Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
USB InterfaceFront panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0
Video Bitrate32 Kbps to 6 Mbps
IP Video Input2-ch (up to 6-ch), Up to 6 MP resolution
Total Bandwidth72 Mbps
Network ProtocolTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF, ISUP
Serial InterfaceRS-485 (half-duplex)
Working Humidity10% to 90%
Audio CompressionG.711u
Network Interface1, RJ45 10/100 Mbps self-adaptive Ethernet interface
Remote Connection32
Video CompressionH.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Analog Video Input4-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
Encoding ResolutionWhen 1080p Lite mode is not enabled: 3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF
Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
Face Picture LibraryUp to 16 face picture libraries
Synchronous playback4-ch
Human/Vehicle AnalysisUp to 2-ch
Dimension (W × D × H)319 × 236 × 48 mm (12.6 × 9.3 × 1.9 inch)
Face Picture ComparisonFace picture comparison, face picture search (1-ch face picture comparison alarm for HD analog camera)
Human/Vehicle Analysis (Motion Detection 2.0)Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by…
