APIOpen Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
EMCFCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN…
SNR≥ 52 dB
DORI2.8 mm, D: 58 m, O: 23 m, R: 11 m, I: 2 m 4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m 6 mm, D: 115 m, O: 45 m, R: 23 m, I: 11 m
Power12 VDC ± 25%, 0.7 A, max. 8.5 W, Ø5.5 mm coaxial power plug PoE: 802.3af, 36 V to 57 V, 0.30 A to 0.18 A, max. 10.5 W
ClientiVMS-4200, Hik-Connect, Hik-Central
SafetyUL (UL 60950-1); CB (IEC 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, IEC 62368-1: 2014); CE-LVD (EN 60950-1: 2005 + Am 1: 2009 + Am 2: 2013, IEC 62368-1: 2014); BIS (IS 13252(Part 1): 2010+A1: 2013+A2: 2015); LOA…
WeightApprox. 1170 g (2.4 lb.)
LinkageUpload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email
ApertureF1.0
Language33 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian…
SecurityPassword protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video…
DimensionØ105 mm × 289.5 mm (Ø4.1″ × 11.4″)
Iris TypeFixed
Lens TypeFixed focal lens, 2.8, 4, and 6 mm optional
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
Reset KeyYes
User/HostUp to 32 users. 3 user levels: administrator, operator and user
H.264 TypeBaseline Profile/Main Profile/High Profile
H.265 TypeMain Profile
Lens MountM16
ProtectionIP67 (IEC 60529-2013)
Sub-Stream50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360) 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
Basic EventMotion detection (human and vehicle targets classification), video tampering alarm, exception
EnvironmentCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Main Stream50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Smart EventLine crossing detection, intrusion detection, region entrance detection, region exiting detection Scene change detection
Web BrowserPlug-in required live view: IE 10, IE 11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+ Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Face CaptureYes
Image Sensor1/1.8" Progressive Scan CMOS
ManufacturerHikvision
Shutter Time1/3 s to 1/100,000 s
Third Stream50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Depth of Field2.8 mm, 2.5 m to ∞ 4 mm, 3.5 m to ∞ 6 mm, 7.5 m to ∞
Image SettingsRotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
Video Bit Rate32 Kbps to 8 Mbps
Max. Resolution2688 × 1520
Network StorageMicroSD/microSDHC/microSDXC card (512 GB) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Together with high-end Hikvision memory card, memory card encryption and health detection are supported
Angle AdjustmentPan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Bit Rate ControlCBR/VBR
Day/Night SwitchAuto, Schedule
General FunctionAnti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter
On-Board StorageBuilt-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
Image EnhancementBLC, HLC, 3D DNR
Min. IlluminationColor: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Package Dimension385 mm × 190 mm × 180 mm (15.2" × 7.5" × 7.1")
Video CompressionMain stream: H.265/H.264/H.265+/H.264+ Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264
Ethernet Interface1 RJ45 10 M/100 M self-adaptive Ethernet port
Focal Length & FOV2.8 mm, horizontal FOV 112°, vertical FOV 61°, diagonal FOV 134° 4 mm, horizontal FOV 95°, vertical FOV 51°, diagonal FOV 115° 6 mm, horizontal FOV 58°, vertical FOV 31°, diagonal FOV 69°
Storage Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
With Package WeightApprox. 1689 g (3.5 lb.)
Supplement Light TypeWhite Light
Simultaneous Live ViewUp to 6 channels
Smart Supplement LightYes
Supplement Light Range60 m
Image Parameters SwitchYes
Lens options at Enspire2.8 mm or 4 mm (tell us which when ordering)
Region of Interest (ROI)1 fixed region for main stream and sub-stream
Wide Dynamic Range (WDR)130 dB
Scalable Video Coding (SVC)H.264 and H.265 encoding
Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
